PRIME | Sophisticated beauty in Mini-ITX design

Sophisticated beauty IN MINI-ITX STANDARD

DESIGNED SPECIALLY FOR MINI-ITX COMPONENTS

Full CNC milling body
7.8 liters volume
Support Mini-ITX Graphics cards
Up to 4 storage drives

ABSOLUTE SYMMETRY IN EVERY DETAIL

Additional Air Vent

Model & Serial number

Mainboard I/O

Graphic card I/O

AC Power Socket

Kensington Lock

Power Button

Power LED (White)

HDD LED (Green)

USB 3.0

UNLEASHED GAMING EXPERIENCE

WITH GIGABYTE™ MINI-ITX GRAPHICS CARDS

Air circulation with lamella design

For successful air circulation, we have applied a vertical lamellar structure.
The lamellar structure has a 1.5 times larger air passage area than the design with a lot of holes.
In the lamellar design, the entire space in front of the motherboard and the GPU participates in the movement of air,
from the top to the bottom. Also, there are no air pockets.

Built FROM ALUMINUM WITH PRECISE CNC MILLING

High precision CNC milling | Grade A matte anodizing finish | Perfect cooling | 7.8 liters volume only
Package content >

No bending

No welding

No punching

No ferrum

No painting

No plastic

OPTIONS	PRIME \| Mini-ITX PC Case v.1.10
Overall dimensions:	280 x 140 x 200mm
Net weight:	2.1kg
Material:	Aluminum 6063. Sandblasted. Black color anodized
Storage:	Up to 2 x 2.5" storage drives
Cooling:	CPU coolers with height up to 50mm
Power Supply:	SFX, SFX-L
USB connectors:	1 External USB 3.0 on front panel
Indicators:	White power LED, green HDD LED on front panel
Mainboards support:	Mini-ITX
PCI-E 16x cards support:	2 slots. Up to 180 x 131mm
